Product features:
1. The rotary wood grabbers are made of special steel ,with light texture,high elasticity and high wear resistance ;
2. Built-in safety valve is used to prevent the cylinder from falling off the arm naturally.
3. Large capacity cylinder design, increase the grasping force of the equipment;
4. The pin is made of alloy steel, built-in butter channel, high strength, good toughness;
5. Rotary motor adopts imported motor; The use of vertical front motor rotation system, 360° rotation, with brake braking function;
6. The grip teeth are made of manganese platinum alloy material, durable.
| Item/Model | Unit | X02 | X04 | X06 | X08 | X10 | X14X20 |
| Weight | kg | 320 | 390 | 740 | 1380 | 1850 | 1900 | 2300 |
| Max jaw opening | mm | 1300 | 1400 | 1800 | 2300 | 2500 | 2500 | 2700 |
| Oil pressure | bar | 110-140 | 120-160 | 150-170 | 160-180 | 160-180 | 180-200 | 180-200 |
| Set up pressure | bar | 170 | 180 | 190 | 200 | 210 | 250 | 250 |
| Opening Flix | lpm | 30-55 | 50-100 | 90-110 | 100-140 | 130-170 | 200-250 | 250-320 |
| Cylinder Volume | ittre | 4.0×1 | 4.5×2 | 8.0×2 | 9.7×2 | 12×2 | 1.2×2 | 14×2 |
| Suitable excavator | Ton | 4-6 | 7-11 | 12-16 | 17-23 | 24-30 | 31-40 | 41-50 |
