Product features:
1. The structure is constructed with high-strength, corrosion-resistant steel plates.
2. The pin shafts are made of alloy steel with integrated oil channels, ensuring superior strength and excellent toughness.
3. The motor is equipped with a hydraulic vibration motor imported from the United States, renowned for its robustness and durability.
4. FAG bearings are utilized, providing low noise levels and ensuring safety and reliability.
5. The damping blocks exhibit exceptional toughness and wear resistance.
| DEHN Compactor | Unit | DN02 | DN04 | DN06 | DN08 | DN10 |
| Weight | kg | 120 | 300 | 500 | 900 | 950 |
| Power of Impulse | ton | 2 | 4 | 6.5 | 15 | 15 |
| Maximum Vibrati o Rate | rpm | 2000 | 2000 | 2000 | 2000 | 2000 |
| Oil Flow | I/min | 30-65 | 45-75 | 85-105 | 120-170 | 120-170 |
| Pressure | kg/cm² | 90-120 | 100-130 | 100-130 | 150-200 | 150-200 |
| Bottom Measurement | L*W*T,mm | 621*350*20 | 920*51*25 | 1040*700*28 | 1353*900*30 | 1353*900*30 |
| Height | mm | 555 | 678 | 854 | 1004 | 1100 |
| Width | mm | 350 | 510 | 700 | 900 | 900 |
| Suitable Excavator | ton | 1-4 | 4-9 | 11-16 | 17-23 | 24-30 |
| Oil pope Diameter | inch | 1/2 | 1/2 | 3/4 | 1 | 1-11/2 |
| A | mm | 195 | 310 | 390 | 465 | 510 |
| B | mm | 621 | 920 | 1040 | 1353 | 1353 |
| C | mm | 555 | 678 | 854 | 1004 | 1026 |
| D | mm | 170 | 250 | 290 | 360 | 450 |
| E | mm | 350 | 510 | 700 | 900 | 900 |
| F | mm | 230 | 370 | 500 | 595 | 635 |
| G | mm | 240 | 330 | 416 | 565 | 570 |
