Product features:
1. Excavator buckets are classified into standard buckets, reinforced buckets, rock buckets, gravel buckets, and grid buckets, etc.
2. The standard bucket is made of high-quality high-strength structural steel 16MN and is suitable for general clay and loose soil excavation and loading in light working environments such as sand, soil, and gravel.
3. The bucket's tooth seat plate and side plates are made of high-wear-resistant steel WH60A and domestic high-quality high-strength materials respectively.
| Total Weight | Unit | 6T | 13T | 15T | 20T | 25T | 30T | 35T | 40T | 45T |
| Standard bucket capacity | cubic | 0.3 | 0.53 | 0.6 | 0.8 | 1.2 | 1.4 | 1.6 | 1.9 | 2.1 |
| weight | kg | 280 | 400 | 500 | 680 | 1100 | 1300 | 1550 | 1900 | 2000 |
Modle | Suitable excavavtor
(ton) | Width(mm) | Pin Diameter(mm) | Weight(kg) | operating
pressure(Bar) | Set Up
Pressure(Kg/m2) | Operating
Flux(LMin) | Cylinder(qty) |
YTSX-02 | 0.8-2 | 900 | 30 | 100 | 80-110 | 120 | 20-35 | single-cylinder |
YTSX-04 | 3-4 | 1000 | 35-40 | 160 | 100-120 | 150 | 25-40 | Single-cylinder |
YTSX-06 | 5-7 | 1200 | 45-50 | 300 | 110-140 | 170 | 30-55 | Double-cylinder |
YTSX-10 | 8-11 | 1500 | 50 | 396 | 120-160 | 180 | 50-100 | Double-cylinder |
